Color Amino Moulding Powder Urea Formaldehyde Melamine Compound for Making Tableware Electrical Appliances Toilet Cover Seat
-
Highlight
Tableware Urea Formaldehyde Moulding Compound
,Electrical Appliances Urea Formaldehyde Moulding Compound
-
FunctionFlame Resistance, Heat Resistance
-
ColorVarious Color
-
AdvantageSuperior Chemical Resistance
-
Specification99.8%
-
HS Code39092000
-
Place of OriginFujian China
-
Brand NameGufaith
-
CertificationCE\ISO
-
Model NumberA111
-
Minimum Order Quantity25kg/bag
-
Packaging Detailswith inner waterproof PE film
-
Delivery Time5-10 work days
-
Payment TermsL/C,D/A,D/P,T/T
-
Supply Ability8000tons/Month
Color Amino Moulding Powder Urea Formaldehyde Melamine Compound for Making Tableware Electrical Appliances Toilet Cover Seat
Color Amino Moulding Powder Urea Formaldehyde Melamine Compound for Making Tableware Electrical Appliances Toliet Cover Seat
UFMC Moulding Powder for Toilet Seats, Bathroom Fittings & Household Products
BIS-Certified Urea Formaldehyde Moulding Compound (UMC) for Sanitaryware Manufacturing
Heat-Resistant UMC Resin Powder - Ideal for Electrical Insulation & Switchgear
Tech index:
| Model | Urea Molding Compound | ||
| Color | White | Technical Standard | GB13454-92 |
| Number | Test Items | Index | Test Result |
| 1 | Fluidity, mm | 140-200 | 195 |
| 2 | Volatile Content % ≤ | 4.00 | 3.95 |
| 3 | Exterior | Qualified | |
| 4 | Boiling Water-proof | Qualified | |
| 5 | Flexural Strength, Mpa ≥ | 90 | 93 |
| 6 | Impact Strength, KJ/sq.m ≥ | 2.1 | 2.15 |
| 7 | Temperature of hot distortion, ºC ≥ | 110 | 125 |
| 8 | Water absorption(Cold water) mg ≤ | 100 | 60 |
| 9 | Molding Shrinkage, % | 0.8 | 0.75 |
| 10 | Dielectric resistance after 24h in water, MΩ ≥ | 104 | 2.6 x 105 |
| 11 | Dielectric Strength, MV/m ≥ | 7.0 | 9 |
| 12 | Arc Resistance S ≥ | 120 | 123 |
| 13 | Molding Time | S | 230-240 |
| 14 | Quantity | Bags | 1 |
| Note | This product can be stored for 6 months under a temperature less than 25ºC. This product tends to absorbing moisture, so place it in a cool and dry place under a temperature less than 25ºC and use it up as soon as possible within 6 months. While taking it out of the bag, take care to avoid dampness and dust. | ||
Synthesis of Urea Formaldehyde (UF) Moulding Compound
1. Raw Materials & Reaction Mechanism
- Core Components:
- Urea (CH₄N₂O) and formaldehyde (CH₂O) in a molar ratio of 1:1.5–2.0 to ensure proper cross-linking.
- Catalysts:
- Alkaline catalysts (e.g., NaOH) for initial polymerization.
- Acidic catalysts (e.g., NH₄Cl or HCOOH) for curing.
- Additives: Optional modifiers (e.g., polyvinyl alcohol or melamine) to enhance mechanical/thermal properties.
2. Synthesis Steps
Step 1: Hydroxymethylation
- Conditions:
- Mix urea and formaldehyde in alkaline conditions (pH 7.2–8.4) at 40–45°C for 10–30 minutes.
- Reaction generates hydroxymethyl urea intermediates.Excavator track roller
Step 2: Condensation Polymerization
- Acid-Catalyzed Reaction:
- Adjust pH to 5.1–5.4 using NH₄Cl or HCOOH to initiate polycondensation.
- Heat to 85–102°C for 1–2 hours to form a branched polymer network with methylene and methylene Gufaith Urea Formaldehyde Moulding Compound linkages.
- Monitor viscosity to determine reaction completion.
Step 3: Neutralization & Stabilization
- Adjust pH back to neutral or weakly alkaline (pH 7–8) to stabilize the resin.
- Cool to <40°C and add final urea batches to reduce free formaldehyde.Making Tableware Color Amino Moulding Powder
Step 4: Moulding Compound Preparation
- Additives:
- Fillers (e.g., cellulose or wood flour) for mechanical strength2.
- Curing accelerators (e.g., ZnSO₄ or oxalate esters) for faster cross-linking.
- Processing:
- Dry and grind the resin into powder.
- Mix with additives and press under 15–30 MPa at 130–160°C to form moulded parts
